Hydro•Sup, Spacer system height "L", for support height 228 - 232 mm Item No. 81523

system height "L", for support height 228 - 232 mm
system height "M", for support height 148 - 152 mm system height "L", for support height 228 - 232 mm

Address

Lang Technik USA
1020 James Dr., Suite I
73271 Hartland, WI 53029

Key data at a glance

This spacer, in conjunction with the Hydro•Sup hydraulic screw jack, provides an additional support surface at a height of between 228 and 232 mm and is, therefore, suitable for the “L” system height of Makro•Grip® Ultra. Together with the Hydro•Sup, it serves to reduce possible vibrations in the machining process of protruding components.

For support height
228 - 232 mm (8.98" - 9.13")
Packaging Unit
1 Piece
Weight
6.6 kg (14.55 lbs)
Material
Steel
Notice:
Scope of delivery:

Hydro•Sup Screw Jack

The hydraulic screw jack Hydro•Sup can be clamped with its clamping stud in the zero-point system as a support when clamping protruding workpieces. The screw jack helps to reduce possible vibrations during the machining process, especially of thin sheet material, which results in a higher surface quality of the manufactured parts.
  • Quality of manufactured parts As a support Hydro•Sup reduces possible vibrations during the machining process.
  • Modularity By the addition of two different spacers which can be mounted to the screw jack, all Makro•Grip® Ultra system heights can be copied.
  • Application diversity Not only applicable for Makro•Grip® Ultra, but also for Makro•Grip® 5-Axis Vises 125 when clamping protruding workpieces.

Learn all about the benefits and functionality of Makro•Grip® Ultra.

Discover now
